Product Description

In tune with the ever-evolving demands of the industry, we are offering a wide range of Unequal Branches. In compliance with the industry standards, the benches are manufactured using premium quality raw materials and leading-edge technology. These benches are offered to our clients in different sizes and shapes that can also be customized as per the specifications at our client's end. In ahead of making the delivery, the provided products are quality tested by our specialists. Our clients can avail these Unequal Branches at leading market prices.

Features:

Rust free nature
Robustness
High strength
Easy installation

Unequal Branches (with & without Access Door)

Angle 0	Nominal Diameter		Dimensions				Approximate Mass of Single Branch		Approximate Mass of Double Branch
Angle 0	Body DN	Branch Pipe dn	e	l	a	b	Plain (Kg)	With Door (Kg)	Plain (Kg)	With Door (Kg)
92.5^o	75	50	3.5	181	39	51	3.1	3.5	3.8	4.2
	100	50	3.5	190	40	63	4.2	4.8	4.5	5.4
	100	75	4.0	211	52	65	4.9	5.5	6.0	6.6
	150	100	5.0	242	67	92	9.1	9.9	10.5	11.3
135^o	75	50	3.5	197	101	106	3.3	3.7	4.0	4.4
	100	50	3.5	210	115	125	4.3	4.9	5.2	5.8
	100	75	4.0	239	133	139	5.5	6.1	6.4	7.0
	150	100	5.0	283	179	190	10.6	11.4	123	13.1
