Cast Iron Door Bend
Product Details:
X
Product Description
Owing to the sincerity and hard work of our professionals, we have been able to carve out a niche for ourselves in this domain by offering a wide variety of Cast Iron Door Bend. Keeping in mind the requirements of our clients, this product is designed using using high-grade of raw materials and sophisticated technology. Dimensional accuracy, abrasion resistance, optimum strength and durability are features that have contributed to the increasing demand for these cast iron products in markets, across the globe. Our clients can avail this Cast Iron Door Bend at market leading rates.
Specifications:
Bends With And Without Access Doors
| Angle | Nominal Diameter DN | Dimensions | Approximate Mass of Bend (kg) | ||||
|---|---|---|---|---|---|---|---|
| e | a | b | Plain | With Door | With Heel rest | ||
| 92.5o (plain) | 75 | 3.5 | 78 | 140 | 2.4 | 2.8 | 2.7 |
| 100 | 4.0 | 91 | 157 | 3.8 | 4.4 | 4.3 | |
| 150 | 5.0 | 117 | 186 | 7.9 | 8.7 | 8.7 | |
| 135o (Half) | 75 | 3.5 | 47 | 104 | 2.1 | | |
| 100 | 4.0 | 53 | 114 | 3.3 | | | |
| 150 | 5.0 | 65 | 129 | 6.5 | | | |
All Dimensions are in Millimeters
